•function:switch
•Type:standalone Rackmount (via mounting bracket)
•network connection:8x RJ-45 2x SFP+
•Speeds:4x RJ-45 (100/1000/25GBase-T) 4x RJ-45 (100/1000/25G/5G/10GBase-T) 2x SFP+ (1G/10Gb/s)
•PoE:8x RJ-45 PoE++ (8x 60W) entire: 295W
•Backplane:140Gb/s 10KB Jumboframes 2MB packet buffer 32K Mac-addresses
•official supported Standards:8021AX 8021 8021D 8021Q 8021ab 8021p 8021s 8021w 8021x 8023 8023ab 8023ae 8023af 8023an 8023at 8023az 8023bt 8023bz 8023u 8023x 8023z IGMPv3 MLDv2
•Configuration:Webinterface serial (USB) configuration software
•Cooling:active 3x fan (40mm)
•Dimensions (WxHxD):330x43x206mm 1U
•Weight:251kg
•Colour:grey blue
•Special features:metal housing detachable mounting bracket firmware updates possible Theft protection (Kensington Lock)
•Warranty:lifetime (10 years in AT/DE)
•Note:For this device \"link aggregation\" was officially specified with the obsolete standard IEEE8023ad Since 2008 the function is no longer administered by the IEEE \"Working Group 3\" (IEEE 8023 CSMA/CD - Ethernet) but by \"Working Group 1\" (IEEE 8021 High Level Interface - Internetworking) and defined technically unchanged via IEEE 8021A
- SKU - Κωδικός Εργοστασίου
- MS510TXUP-100EUS
